Where can you find our references?
Home > Our products > Silentblocs > M/M Anti-Vibration mount > M/M Anti-Vibration mount D.40mm

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
Print

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
5.91 € HT Piece
7.09 € TTC
Available
-
+
Print
Features
Reference
LE SR0
Material
Steel
Thread
isometric
Height
28 mm
Thread height
25 mm
Thread diameter
M10
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
5.54 € HT Piece
6.65 € TTC
Available
-
+
Print
Features
Reference
LE SR08NM8X20
Material
Steel
Thread
isometric
Height
28 mm
Thread height
30 mm
Thread diameter
M8
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
5.80 € HT Piece
6.96 € TTC
Available
-
+
Print
Features
Reference
LE SR0M8
Material
Steel
Thread
isometric
Height
28 mm
Thread height
30 mm
Thread diameter
M8
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
6.40 € HT Piece
7.68 € TTC
Available
-
+
Print
Features
Reference
LE SR0NM10
Material
Steel
Thread
isometric
Height
28 mm
Thread height
25 mm
Thread diameter
M10
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
5.64 € HT Piece
6.77 € TTC
Available
-
+
Print
Features
Reference
LE SR0NM8
Material
Steel
Thread
isometric
Height
28 mm
Thread height
30 mm
Thread diameter
M8
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
5.89 € HT Piece
7.07 € TTC
Available
-
+
Print
Features
Reference
LE SR4020
Material
Steel
Thread
isometric
Height
20 mm
Thread height
25 mm
Thread diameter
M10
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
5.78 € HT Piece
6.94 € TTC
Unavailable
-
+
Add to cart
Print
Features
Reference
LE SR4028
Material
Steel
Thread
isometric
Height
28 mm
Thread height
25 mm
Thread diameter
M10
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
6.94 € HT Piece
8.33 € TTC
Available
-
+
Print
Features
Reference
LE SR4035
Material
Steel
Thread
isometric
Height
35 mm
Thread height
25 mm
Thread diameter
M10
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
6.74 € HT Piece
8.09 € TTC
Available
-
+
Print
Features
Reference
LE SR4040
Material
Steel
Thread
isometric
Height
40 mm
Thread height
25 mm
Thread diameter
M10
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
6.06 € HT Piece
7.27 € TTC
Unavailable
-
+
Add to cart
Print
Features
Reference
LE SR4040M8
Material
Steel
Thread
isometric
Height
40 mm
Thread height
20 mm
Thread diameter
M8
Diameter
40 mm
Hardness
50

M/M Anti-Vibration mount D.40mm

Height 20 to 45 mm | Thread M8 et M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
6.85 € HT Piece
8.22 € TTC
Available
-
+
Print
Features
Reference
LE SR4045
Material
Steel
Thread
isometric
Height
45 mm
Thread height
25 mm
Thread diameter
M10
Diameter
40 mm
Hardness
50
