Home > Our products > Silentblocs > M/M Anti-Vibration mount > M/M Anti-Vibration mount D.25mm

M/M Anti-Vibration mount D.25mm

Height 10 to 40 mm | Thread M6 et M8

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
Print

M/M Anti-Vibration mount D.25mm

Height 10 to 40 mm | Thread M6 et M8

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
4.61 € HT Piece
5.53 € TTC
Available
-
+
Print
Features
Reference
LE SR2510
Material
Steel
Thread
isometric
Height
10 mm
Thread height
20 mm
Thread diameter
M8
Diameter
25 mm
Hardness
50

M/M Anti-Vibration mount D.25mm

Height 10 to 40 mm | Thread M6 et M8

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
4.55 € HT Piece
5.46 € TTC
Available
-
+
Print
Features
Reference
LE SR2515
Material
Steel
Thread
isometric
Height
15 mm
Thread height
20 mm
Thread diameter
M8
Diameter
25 mm
Hardness
50

M/M Anti-Vibration mount D.25mm

Height 10 to 40 mm | Thread M6 et M8

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
3.44 € HT Piece
4.13 € TTC
Available
-
+
Print
Features
Reference
LE SR2520
Material
Steel
Thread
isometric
Height
20 mm
Thread height
20 mm
Thread diameter
M8
Diameter
25 mm
Hardness
50

M/M Anti-Vibration mount D.25mm

Height 10 to 40 mm | Thread M6 et M8

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
4.49 € HT Piece
5.39 € TTC
Available
-
+
Print
Features
Reference
LE SR2525
Material
Steel
Thread
isometric
Height
25 mm
Thread height
20 mm
Thread diameter
M8
Diameter
25 mm
Hardness
50

M/M Anti-Vibration mount D.25mm

Height 10 to 40 mm | Thread M6 et M8

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
4.67 € HT Piece
5.60 € TTC
Available
-
+
Print
Features
Reference
LE SR2525M6X25
Material
Steel
Thread
isometric
Height
25 mm
Thread height
16 mm
Thread diameter
M6
Diameter
25 mm
Hardness
50

M/M Anti-Vibration mount D.25mm

Height 10 to 40 mm | Thread M6 et M8

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
4.76 € HT Piece
5.71 € TTC
Available
-
+
Print
Features
Reference
LE SR2530
Material
Steel
Thread
isometric
Height
30 mm
Thread height
20 mm
Thread diameter
M8
Diameter
25 mm
Hardness
50

M/M Anti-Vibration mount D.25mm

Height 10 to 40 mm | Thread M6 et M8

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
5.56 € HT Piece
6.67 € TTC
Unavailable
-
+
Add to cart
Print
Features
Reference
LE SR2530M6
Material
Steel
Thread
isometric
Height
30 mm
Thread height
16 mm
Thread diameter
M6
Diameter
25 mm
Hardness
50

M/M Anti-Vibration mount D.25mm

Height 10 to 40 mm | Thread M6 et M8

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
4.72 € HT Piece
5.66 € TTC
Unavailable
-
+
Add to cart
Print
Features
Reference
LE SR2540
Material
Steel
Thread
isometric
Height
40 mm
Thread height
20 mm
Thread diameter
M8
Diameter
25 mm
Hardness
50
